紧凑的机体 - 允许使用更小的机柜,或者安装在使用点附近。
光学隔离的输入/输出、自锁连接器以及全方位的故障防护,更是提高了机器寿命和抗故障损坏能力。
高性能系统 - 提高机器产能并延长机器寿命。
易于使用的GUI(图形用户接口) - 缩短工程与技术支持时间。
缩减的总成本
易于使用
|
Model |
||||
Rated data |
DIM |
20330 |
20630 |
20260 |
20360 |
Rated supply voltage |
V |
20 ... 90 VDC |
0 ... 264 VAC |
||
Control logic, supply voltage |
V |
10 ... 90 VDC |
85 ... 265 VAC |
||
Rated output current (RMS value, ± 3 %) |
A |
3 |
6 |
1.5 |
3 |
Peak output current (± 3 %) |
A |
9 |
18 |
4.5 |
9 |
Peak time |
s |
3 |
3 |
3 |
3 |
Current loop Bandwidth max. |
kHz |
5 |
5 |
3 |
3 |
Velocity loop Bandwidth max. |
Hz |
800 |
|||
Update rate |
MHz |
1.25 |
DC
DC & option
AC
Height
152.4 mm
152.4 mm
175 mm
Width
28.7 mm
48.3 mm
54.8 mm
Depth without connectors
101 mm
101 mm
132 mm
Depth with connectors
~130 mm
~130 mm
~180 mm
